Zeus
02.07.2024
If not otherwise specified:
Dist/Dim in meters
Weights in m.tones
All details given in good faith without any guarantee
- Ex.
- IMO No
- 9199684
- Call sign
- V2OR
- Build
- 2000
- Flag
- ATG
- Builders
- Classification
- BV / I HULL MACH General cargo ship -heavycargo ((Tanktop, 150 kN/m2 - Hatch cover, 17.5kN/m2)); Conatiner ship Unrestricted navigation Ice class IB AUT-UMS
- Length oa
- 89.71
- Breadth mld
- 11.65
- Depth mld
- 5.8
- Draft summer
- 4.48
- Deadweight summer draft
- 2439
- Draft winter
- 4.38
- Deadweight winter draft
- 2370
- Gross tonnage
- 1846
- Net tonnage
- 1081
- Immersion(load draft) TPC
- 9.56
- Mean draft of ship in heavy ballast
- 3.12
- Distance from forward end of No. 1 hatch to aft end of last hatch
- 57.81
- Hatch type
- Kvaerner Multifold, Crocodile
- Container (TEU) capacity Hold / Deck
- 52 / 72
- Max permissible load on deck/hatch-cover, mt/sqm
- 1.56
- Max permissible load on tanktop, mt/sqm
- 15
- Max air draft - 1
- 19.88
- Max air draft - 2
- 8.48
- Water ballast capacity
- 1130
- MGO Capacity (Cbm)
- 147
- IFO Capacity (Cbm)
- 0
- Service speed, knots
- 10
- A60
- No
- Bow thruster
- 185 kW, Yes
- Boxed
- Yes
- Open hatch
- Yes
- Rhine fitted
- Yes
- Ammonium Nitrate fitted
- Yes
- FeSi fitted
- Yes
- Keel to top antenna fwd/aft
- 0 / 23.1
- Keel to top antenna fwd/aft - lowered mast
- 0 / 11.85
Remarks:
Vessel fitted with 2 movable bulkheads, 8 different positions. Free length on tanktop with both bulkheads in aft storage position about 58.50m. NAABSA Fitted A60
| Htch# | a | b | c | d | e | f | g |
|---|---|---|---|---|---|---|---|
| 1 | 4.68 | 3.32 | 6.85 | 0.156 | 1.18 | 2 | 57.81 x 9.3 |
a : Distance from waterline fully ballasted to top of hatch coamings
b : Distance from waterline fully loaded to top of hatch coamings
c : Distance from tank top to top of hatch coamings
d : Max permissable loading on hatch covers
e : Distance from ship's rail to inside hatch coamings
f : Height of hatch coamings
g : Hatch opening
h : No. of Loadingholes on hatchcovers X diameter in mm
| Bale | Grain | ||||
|---|---|---|---|---|---|
| Hold# | cbm | cbft | cbm | cbft | Hold dimensions |
| 1 | 3582 | 126497 | 3761 | 132824 | 57.81 x 9.3 x 6.85 |
| Compartments | ||||||||
|---|---|---|---|---|---|---|---|---|
| a | b | c | d | e | f | g | h | i |
| 562 | 196 | 430 | 851 | 92 | 700 | 508 | 196 | 226 |
