Wilson Wedau
17.01.2025
If not otherwise specified:
Dist/Dim in meters
Weights in m.tones
All details given in good faith without any guarantee
- Ex.
- RMS Ruhrort
- IMO No
- 9987079
- Call sign
- 8PWO1
- Build
- 2024
- Flag
- BRB
- Builders
- Classification
- BV - I * HULL * MACH General cargo ship - heavycargo(147) Unrestricted naviagtion* AUT-UMS
- Length oa
- 87.588
- Breadth mld
- 11.4
- Depth mld
- 5.5
- Draft summer
- 4.67
- Deadweight summer draft
- 2898
- Draft winter
- 4.67
- Deadweight winter draft
- 2898
- Gross tonnage
- 1952
- Net tonnage
- 1034
- Immersion(load draft) TPC
- 10
- Mean draft of ship in heavy ballast
- 0
- Distance from forward end of No. 1 hatch to aft end of last hatch
- 62.82
- Hatch type
- Container (TEU) capacity Hold / Deck
- 0 / 30
- Max permissible load on deck/hatch-cover, mt/sqm
- 15
- Max permissible load on tanktop, mt/sqm
- 1.5
- Max air draft - 1
- 0
- Max air draft - 2
- 0
- Water ballast capacity
- 1404
- MGO Capacity (Cbm)
- 0
- IFO Capacity (Cbm)
- 0
- Service speed, knots
- 0
- A60
- No
- Bow thruster
- 200 kW, Yes
- Boxed
- No
- Open hatch
- No
- Rhine fitted
- No
- Ammonium Nitrate fitted
- Yes
- FeSi fitted
- No
- Keel to top antenna fwd/aft
- 17.7 / 21.6
- Keel to top antenna fwd/aft - lowered mast
- 0 / 0
Remarks:
1 movable bulkhead. 6 positions Bulkhead between Cargo hold and Engine romm is not insulated. Cargos requiering A60, the bulkhead must be used in aft position 3m away from engine bulk head.
| Htch# | a | b | c | d | e | f | g |
|---|---|---|---|---|---|---|---|
| 1 | 4.24 | 2.835 | 6.538 | 1.5 | 1.18 | 2.01 | 5.1 x 5.1 |
a : Distance from waterline fully ballasted to top of hatch coamings
b : Distance from waterline fully loaded to top of hatch coamings
c : Distance from tank top to top of hatch coamings
d : Max permissable loading on hatch covers
e : Distance from ship's rail to inside hatch coamings
f : Height of hatch coamings
g : Hatch opening
h : No. of Loadingholes on hatchcovers X diameter in mm
| Bale | Grain | ||||
|---|---|---|---|---|---|
| Hold# | cbm | cbft | cbm | cbft | Hold dimensions |
| 1 | 3200 | 113007 | 3535 | 124837 | 58.8 x 9 x 6.538 |
| Compartments | |||||||
|---|---|---|---|---|---|---|---|
| a | b | c | d | e | f | g | h |
| 255 | 554 | 553 | 554 | 554 | 554 | 380 | 116 |
