Wilson Palma

02.07.2024

If not otherwise specified:
Dist/Dim in meters
Weights in m.tones

All details given in good faith without any guarantee

Ex.
Tejo Belem
IMO No
9368417
Call sign
LATW8
Build
2009
Flag
NIS
Builders
Classification
DNV 100 A5 Multi-purpose dry cargo ship DBC IW Strengthened for heavy cargo MC AUT
Length oa
89.5
Breadth mld
13.7
Depth mld
8
Draft summer
6
Deadweight summer draft
4597
Draft winter
6
Deadweight winter draft
4597
Gross tonnage
2956
Net tonnage
1558
Immersion(load draft) TPC
11.28
Mean draft of ship in heavy ballast
3.85
Distance from forward end of No. 1 hatch to aft end of last hatch
0
Hatch type
Pontoon, Gantry Crane
Container (TEU) capacity Hold / Deck
0 / 111
Max permissible load on deck/hatch-cover, mt/sqm
3.2
Max permissible load on tanktop, mt/sqm
12
Max air draft - 1
21.9
Max air draft - 2
0
Water ballast capacity
1792
MGO Capacity (Cbm)
285
IFO Capacity (Cbm)
0
Service speed, knots
0
A60
No
Bow thruster
No
Boxed
Yes
Open hatch
Yes
Rhine fitted
No
Ammonium Nitrate fitted
Yes
FeSi fitted
Yes
Keel to top antenna fwd/aft
21.45 / 27.9
Keel to top antenna fwd/aft - lowered mast
0 / 0

Remarks:

2 movable bulkheads 5 cement holes Engine Room boundaries: Bulkheads between cargo hold and machinery spaces of category A are not insulated to A-60 standard.

Htch# g h
1 60.77 x 10.97 5 x 0

a : Distance from waterline fully ballasted to top of hatch coamings
b : Distance from waterline fully loaded to top of hatch coamings
c : Distance from tank top to top of hatch coamings
d : Max permissable loading on hatch covers
e : Distance from ship's rail to inside hatch coamings
f : Height of hatch coamings
g : Hatch opening
h : No. of Loadingholes on hatchcovers X diameter in mm

Bale Grain
Hold# cbm cbft cbm cbft Hold dimensions
1 5550 195996 5550 195996 61.71 x 10.97 x 8.39
