Wilson Flex V

21.01.2025

If not otherwise specified:
Dist/Dim in meters
Weights in m.tones

All details given in good faith without any guarantee

Ex.
IMO No
9911472
Call sign
CQER3
Build
2023
Flag
PRT
Builders
Classification
DNV 1A Multi-purpose dry cargo ship BIS BWM(T) DBC DG(B, P) E0 Grab(2-15 t) Hatchcoverless LCS NAABSA NAUT(NAV) Strengthened(IB) TMON(oil lubricated) ER(SCR, TIER III)
Length oa
88.5
Breadth mld
14.54
Depth mld
7.4
Draft summer
5.7
Deadweight summer draft
4282
Draft winter
5.58
Deadweight winter draft
4122
Gross tonnage
2995
Net tonnage
1563
Immersion(load draft) TPC
11.8
Mean draft of ship in heavy ballast
4
Distance from forward end of No. 1 hatch to aft end of last hatch
60.8
Hatch type
Pontoon
Container (TEU) capacity Hold / Deck
0 / 84
Max permissible load on deck/hatch-cover, mt/sqm
2.5
Max permissible load on tanktop, mt/sqm
15
Max air draft - 1
21.13
Max air draft - 2
0
Water ballast capacity
1838
MGO Capacity (Cbm)
181
IFO Capacity (Cbm)
0
Service speed, knots
10
A60
Yes
Bow thruster
300 kW, Yes
Boxed
Yes
Open hatch
Yes
Rhine fitted
No
Ammonium Nitrate fitted
Yes
FeSi fitted
Yes
Keel to top antenna fwd/aft
26.83 / 16.86
Keel to top antenna fwd/aft - lowered mast
18.5 / 16.86

Remarks:

Open - Bulk Head Positions: 20 Open Top Max Draft Open Top: 4.60m Deadweight Open Top: 2918mt

a : Distance from waterline fully ballasted to top of hatch coamings
b : Distance from waterline fully loaded to top of hatch coamings
c : Distance from tank top to top of hatch coamings
d : Max permissable loading on hatch covers
e : Distance from ship's rail to inside hatch coamings
f : Height of hatch coamings
g : Hatch opening
h : No. of Loadingholes on hatchcovers X diameter in mm

Bale Grain
Hold# cbm cbft cbm cbft Hold dimensions
1 5460 192818 5460 192818 56 x 11.3 x 8.633
