Wilson Flex II
03.04.2025
If not otherwise specified:
Dist/Dim in meters
Weights in m.tones
All details given in good faith without any guarantee
- Ex.
- IMO No
- 9911446
- Call sign
- CQEZ5
- Build
- 2022
- Flag
- PRT
- Builders
- Classification
- DNV 1A Multi-purpose dry cargo ship BIS BWM(T) DBC DG(B, P) E0 Grab(2-15 t) Hatchcoverless LCS NAABSA NAUT(NAV) Strengthened(IB) TMON(oil lubricated) ER(SCR, TIER III)
- Length oa
- 88.5
- Breadth mld
- 14.54
- Depth mld
- 7.35
- Draft summer
- 5.7
- Deadweight summer draft
- 4267
- Draft winter
- 5.58
- Deadweight winter draft
- 4122
- Gross tonnage
- 2995
- Net tonnage
- 1563
- Immersion(load draft) TPC
- 11.8
- Mean draft of ship in heavy ballast
- 4
- Distance from forward end of No. 1 hatch to aft end of last hatch
- 60.8
- Hatch type
- Pontoon
- Container (TEU) capacity Hold / Deck
- 0 / 84
- Max permissible load on deck/hatch-cover, mt/sqm
- 2.5
- Max permissible load on tanktop, mt/sqm
- 15
- Max air draft - 1
- 21.13
- Max air draft - 2
- 0
- Water ballast capacity
- 1838
- MGO Capacity (Cbm)
- 181
- IFO Capacity (Cbm)
- 0
- Service speed, knots
- 10
- A60
- Yes
- Bow thruster
- 300 kW, Yes
- Boxed
- Yes
- Open hatch
- Yes
- Rhine fitted
- No
- Ammonium Nitrate fitted
- Yes
- FeSi fitted
- Yes
- Keel to top antenna fwd/aft
- 26.83 / 16.86
- Keel to top antenna fwd/aft - lowered mast
- 18.5 / 16.86
Remarks:
Open - Bulk Head Positions: 20 Open Top Max Draft Open Top: 4.60m Deadweight Open Top: 2918mt
| Htch# | a | b | c | d | e | f | g | h |
|---|---|---|---|---|---|---|---|---|
| 1 | 6.2 | 4.43 | 8.652 | 2.5 | 1.35 | 2.78 | 60.8 x 11.3 | 10 x 0.53 |
a : Distance from waterline fully ballasted to top of hatch coamings
b : Distance from waterline fully loaded to top of hatch coamings
c : Distance from tank top to top of hatch coamings
d : Max permissable loading on hatch covers
e : Distance from ship's rail to inside hatch coamings
f : Height of hatch coamings
g : Hatch opening
h : No. of Loadingholes on hatchcovers X diameter in mm
| Bale | Grain | ||||
|---|---|---|---|---|---|
| Hold# | cbm | cbft | cbm | cbft | Hold dimensions |
| 1 | 5460 | 192818 | 5460 | 192818 | 56 x 11.3 x 8.633 |
