Wilson Dordrecht
20.05.2025
If not otherwise specified:
Dist/Dim in meters
Weights in m.tones
All details given in good faith without any guarantee
- Ex.
- Kine
- IMO No
- 9145140
- Call sign
- 8PAR2
- Build
- 1996
- Flag
- BRB
- Builders
- Classification
- DNV GL / 100 A5 E General cargo ship with Double hull Equipped for carriage of Containers DBC SOLAS-II-2 Reg.19 G MC E AUT
- Length oa
- 88.56
- Breadth mld
- 11.35
- Depth mld
- 6.4
- Draft summer
- 4.956
- Deadweight summer draft
- 3006
- Draft winter
- 4.853
- Deadweight winter draft
- 2908
- Gross tonnage
- 2061
- Net tonnage
- 1161
- Immersion(load draft) TPC
- 9.6
- Mean draft of ship in heavy ballast
- 3
- Distance from forward end of No. 1 hatch to aft end of last hatch
- 57.5
- Hatch type
- MacGregor
- Container (TEU) capacity Hold / Deck
- 72 / 48
- Max permissible load on deck/hatch-cover, mt/sqm
- 1.6
- Max permissible load on tanktop, mt/sqm
- 12
- Max air draft - 1
- 19.5
- Max air draft - 2
- 9.5
- Water ballast capacity
- 1152
- MGO Capacity (Cbm)
- 135
- Service speed, knots
- 9
- A60
- No
- Bow thruster
- 175 kW, Yes
- Boxed
- Yes
- Open hatch
- Yes
- Rhine fitted
- Yes
- Ammonium Nitrate fitted
- Yes
- FeSi fitted
- No
- Keel to top antenna fwd/aft
- 19.5 / 23
- Keel to top antenna fwd/aft - lowered mast
- 12.5 / 12.7
Remarks:
NAABSA Two moveable bulkheads
| Htch# | a | b | c | d | e | f | g |
|---|---|---|---|---|---|---|---|
| 1 | 6 | 4 | 8.06 | 1.6 | 0.87 | 2.47 | 57 x 9.01 |
a : Distance from waterline fully ballasted to top of hatch coamings
b : Distance from waterline fully loaded to top of hatch coamings
c : Distance from tank top to top of hatch coamings
d : Max permissable loading on hatch covers
e : Distance from ship's rail to inside hatch coamings
f : Height of hatch coamings
g : Hatch opening
h : No. of Loadingholes on hatchcovers X diameter in mm
| Bale | Grain | ||||
|---|---|---|---|---|---|
| Hold# | cbm | cbft | cbm | cbft | Hold dimensions |
| 1 | 4156 | 146768 | 4156 | 146768 | 57.5 x 9.01 x 8.06 |
| Compartments | ||||||||
|---|---|---|---|---|---|---|---|---|
| a | b | c | d | e | f | g | h | i |
| 499 | 436 | 436 | 428 | 436 | 436 | 436 | 436 | 622 |
