Ems Lion
08.12.2025
If not otherwise specified:
Dist/Dim in meters
Weights in m.tones
All details given in good faith without any guarantee
- Ex.
- IMO No
- 9978901
- Call sign
- V2RC4
- Build
- 2024
- Flag
- ATG
- Builders
- Classification
- RINA
- Length oa
- 93.5
- Breadth mld
- 14.4
- Depth mld
- 5.18
- Draft summer
- 5.18
- Deadweight summer draft
- 4399
- Draft winter
- 5.062
- Deadweight winter draft
- 3960
- Gross tonnage
- 2993
- Net tonnage
- 1412
- Immersion(load draft) TPC
- 0
- Mean draft of ship in heavy ballast
- 3.5
- Distance from forward end of No. 1 hatch to aft end of last hatch
- 62
- Hatch type
- Pontoon
- Container (TEU) capacity Hold / Deck
- 0 / 0
- Max permissible load on deck/hatch-cover, mt/sqm
- 2
- Max permissible load on tanktop, mt/sqm
- 15
- Max air draft - 1
- 22.1
- Max air draft - 2
- 0
- Water ballast capacity
- 2098
- MGO Capacity (Cbm)
- 0
- Service speed, knots
- 0
- A60
- No
- Bow thruster
- 215 kW, Yes
- Boxed
- Yes
- Open hatch
- No
- Rhine fitted
- No
- Ammonium Nitrate fitted
- Yes
- FeSi fitted
- Yes
- Keel to top antenna fwd/aft
- 0 / 25.6
- Keel to top antenna fwd/aft - lowered mast
- 0 / 0
Remarks:
2 moveable bulkheads. 12 bulkhead positions.
| Htch# | a | b | c | d | e | f | g |
|---|---|---|---|---|---|---|---|
| 1 | 5.6 | 3.92 | 7.49 | 2 | 1.03 | 2 | 61.6 x 11.8 |
a : Distance from waterline fully ballasted to top of hatch coamings
b : Distance from waterline fully loaded to top of hatch coamings
c : Distance from tank top to top of hatch coamings
d : Max permissable loading on hatch covers
e : Distance from ship's rail to inside hatch coamings
f : Height of hatch coamings
g : Hatch opening
h : No. of Loadingholes on hatchcovers X diameter in mm
| Bale | Grain | ||||
|---|---|---|---|---|---|
| Hold# | cbm | cbft | cbm | cbft | Hold dimensions |
| 1 | 5363 | 189393 | 5363 | 189392 | 61.6 x 11.8 x 7.4 |
